ASRock Rack 2U GPU Syetem 2U4G-C621WS 2Uラックマウント型サーバーベアボーン - ショッピング・ショップ | 通販検索

商品説明

2U4G-C621WS

[特徴]

・2U Rackmount with 2000W Redundant PSU (1+1)

・Dual Socket P (Purley) Intel Xeon Scalable Processors

・Support 12 x DDR4 DIMM slot, 2666/2400 RDIMM, LR DIMM

・Supports 4 x GPGPU/MIC, 1 X PCIE

・Supports 4 x GLAN by Marvell 88E1543

・Supports 4 x2.5" SATA 6GB/s HDDs(1x SATA3 HDD could support NVME* or SATA3 6GB/s HDDs) + 1x NVME*

・Supports 1 x PCIE card (through riser card)

[仕様]

システム概要 Form Factor- 2U Rackmount

Chassis Model- 2U4G-C621WS

Dimensions- 438x 795x 87.5 mm(without ear)

Support MB- EEB, 12 x 13 inch (EP2C621D12 WS) フロントパネル Buttons

- Power button

- UID button

LEDs

- 2 x LAN LEDs (L1, L2, LED)

- System event LED

I/O Ports- 2 x USB 2.0 ports 外部ドライブベイ / Storage Front Side Drive Bay- 4 x2.5" SATA 6GB/s HDDs(1x SATA3 HDD could support NVME or SATA3 6GB/s HDDs) + 1x NVME 電源装置 Type- 2 (1+1), Redundant

Output Watts- 2000W, Platinum

AC Input- High Line 200-240V, 50/60Hz システムファン Fan- 80 x 38 mm x 6 System Switch board Switch IC- NA GPGPU card GPGPU Watts- Max 300w /per card (if use half width card, max 150W)

Support GPGPU- 4 x PCIE X16 GPGPU/MIC card (Double width) or 8 x PCIE X8 GPU/PCIE card (half width) Physical Status Form Factor- EEB

Dimensions- 12''x13'' プロセッサ システム CPU- Intel Xeon Scalable Processors (Max 205W)

Socket- Dual Socket P

Chipset- Intel C621 システム メモリ Capacity- 12 DIMM slots

Type

- 6 Channels memory technology

- Support DDR4 2666/2400/2133 RDIMM & LR DIMM

DIMM Size Per DIMM

- R/LR DIMM: 32GB, 16GB, 8GB, 4GB

- NVDIMM: 64GB, 32GB

DIMM Frequency

- R DIMM: 2666/2400/2133 MHz

- LR DIMM: 2666/2400/2133 MHz

- NVDIMM: 2666/2400/2133 MHz

Voltage- 1.2V 拡張スロット PCIE/GPGPU Card

- Front : 6 x single-width / 3 x double-width cards

- Rear : 1 x single-width / 2 x double-width cards

- 1 x PCIEx16 card (through riser card)

M.2- 2 (2230/2242/2260/2280 by PCIE & SATA interface) ストレージ SATA Controller- Intel® C621 : SATA3 6.0 Gb/s Ethernet Interface- 1000 /100 /10 Mbps

LAN Controller- 4 x RJ45 by Marvell 88E1543 for 4 ports GbE 管理機能 BMC Controller- ASPEED AST2500 IPMI Dedicated GLAN- 1 x Realtek RTL8211E for dedicated management GLAN Features- Watch Dog - NMI グラフィックス機能 Controller- ASPEED AST2500

VRAM- DDR4 4G オーディオ Audio Codec- Realtek ALC892 バックパネルインターフェース PS/2 KB/Mouse- 1

VGA Port- 1 x D-Sub

USB 3.2 Gen1 Port- 4

Lan Port

- 4+1(IPMI) RJ45 Gigabit Ethernet LAN port

- LAN Ports with LED (ACT/LINK LED and SPEED LED)

Audio- 5+1 Jack Internal Connector SATA DOM- 2 (shar with sSATA 2&3)

M.2- 0

TPM Header- 1 Onboard LED 80 Debug Port LED- 1 System BIOS BIOS Type- 256MB AMI UEFI Legal BIOS

BIOS Features

- Plug and Play (PnP)

- ACPI 2.0 Compliance Wake Up Events

- SMBIOS 2.8 Support

- ASRock Rack Instant Flash Hardware Monitor Temperature

- CPU Temperature Sensing

- System Temperature Sensing

Fan

- CPU/Rear/Front Fan Tachometer

- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature)

- CPU/Rear/Front Fan Multi-Speed Control

Voltage- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, 1.05V_PCH, +BAT, 3VSB, 5VSB Environment TemperatureOperation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C JAN：2000160344905
